WordPress on Kubernetes Needs More Than a Pod

Most WordPress-on-Kubernetes tutorials stop at the point where the site answers HTTP.

That is useful for a demo, but it is not the point where WordPress becomes operable. A production setup has to answer harder questions: where does mutable content live, how are plugins installed without manual dashboard drift, how does object cache survive pod restarts, how are database and wp-content backed up together, and how do secrets flow from the platform into the chart without placing passwords directly in values.yaml.

The HelmForge WordPress chart was shaped around that operational contract. The default path is still intentionally small for development, but the production path exposes the decisions you need to make explicit.

What is different from a generic setup

The common Kubernetes version of WordPress is a Deployment, a Service, a PVC, and a MySQL database. That is only the runtime skeleton.

The useful unit is larger:

• WordPress running from the official Apache image.
• MySQL from the HelmForge subchart or an external MySQL/MariaDB service.
• A persistent volume for /var/www/html.
• Optional Redis Object Cache with the official redis-cache plugin.
• A post-install/post-upgrade plugin installer Job for official WordPress.org plugin slugs.
• S3-compatible backup that exports both the database and wp-content.
• Ingress or Gateway API routing.
• Optional External Secrets Operator resources for admin, database, backup, and Redis credentials.
• Optional NetworkPolicy, ServiceAccount token controls, HPA, PDB, wp-cron CronJob, metrics, and dual-stack Service fields.

That sounds like more YAML, but it removes a lot of manual state from the WordPress dashboard and makes the deployment reviewable before it reaches a cluster.

Start with a development install

The default install is deliberately convenient:

helm repo add helmforge https://repo.helmforge.dev
helm repo update

helm install wordpress helmforge/wordpress \
  --namespace wordpress \
  --create-namespace \
  --wait --timeout 10m

That gives you one WordPress pod, a bundled HelmForge MySQL database, generated credentials, and a persistent WordPress volume.

For local access:

kubectl port-forward -n wordpress svc/wordpress 8080:80

This is the right shape for development, demos, and chart validation. It is not the final production shape, because generated credentials, default resources, single-replica RWO storage, and dashboard-managed plugins are not enough for a managed service.

Make the production contract explicit

A production-oriented values file should start by deciding the URL, secrets, database, storage, routing, and backup path:

wordpress:
  siteUrl: https://blog.example.com
  siteTitle: Engineering Blog
  adminEmail: platform@example.com
  forceSSLAdmin: true
  disallowFileEdit: true
  disableWpCron: true
  memoryLimit: 256M
  maxMemoryLimit: 512M

admin:
  existingSecret: wordpress-admin
  existingSecretPasswordKey: admin-password

mysql:
  enabled: false

database:
  mode: external
  external:
    host: mysql-primary.wordpress.svc.cluster.local
    port: 3306
    name: wordpress
    username: wordpress
    existingSecret: wordpress-db
    existingSecretPasswordKey: password

persistence:
  enabled: true
  accessMode: ReadWriteMany
  storageClass: nfs-rwx
  size: 50Gi

service:
  ipFamilyPolicy: PreferDualStack
  ipFamilies:
    - IPv4
    - IPv6

gatewayAPI:
  enabled: true
  parentRefs:
    - name: public
      namespace: gateway-system
      sectionName: https
  hostnames:
    - blog.example.com

networkPolicy:
  enabled: true
  ingress:
    extraFrom:
      - namespaceSelector:
          matchLabels:
            kubernetes.io/metadata.name: gateway-system
  egress:
    enabled: true
    allowDNS: true
    allowSameNamespaceDatabase: true
    allowHTTPS: true

wpCron:
  cronJob:
    enabled: true

pdb:
  enabled: true
  minAvailable: 1

resources:
  requests:
    cpu: 250m
    memory: 512Mi
  limits:
    cpu: '1'
    memory: 1Gi

This values file says what the platform owns and what the chart wires into the workload. The Gateway, certificate automation, secret backend, external database, DNS, storage class, and S3 bucket are still platform concerns. The chart consumes them consistently.

Redis is not just another sidecar

WordPress has an in-memory object cache during a single request, but a persistent object cache needs a backend and a drop-in. Redis matters because it moves repeated query and transient lookups out of MySQL, which is especially useful for WooCommerce, large admin screens, multisite, ACF-heavy sites, and traffic with repeated anonymous reads.

The chart uses the official Redis Object Cache plugin path:

• install and activate redis-cache.
• create the wp-content/object-cache.php drop-in.
• set the WordPress Redis constants.
• point WordPress to either a HelmForge Redis subchart or an external Redis service.
• share Redis credentials with the WordPress pod and the installer Job when auth is enabled.

Using the HelmForge Redis subchart:

plugins:
  enabled: true
  installer:
    enabled: true
    activeDeadlineSeconds: 60

objectCache:
  enabled: true
  redis:
    mode: subchart
    subchart:
      enabled: true

redis:
  architecture: standalone
  auth:
    existingSecret: wordpress-redis-auth
    existingSecretPasswordKey: redis-password

Using an external Redis:

plugins:
  enabled: true
  installer:
    enabled: true

objectCache:
  enabled: true
  redis:
    mode: external
    external:
      host: redis.cache.svc.cluster.local
      port: 6379
    auth:
      existingSecret: wordpress-redis
      existingSecretPasswordKey: redis-password

The important validation is not only “the Redis pod is running.” The real check is that WordPress installed the plugin, created the drop-in, connected to Redis, and can write cache keys.

kubectl logs -n wordpress job/wordpress-plugin-installer

kubectl exec -n wordpress deploy/wordpress -- \
  wp redis status --path=/var/www/html --allow-root

If Redis is unavailable, the object cache drop-in becomes part of the availability story. That is why Redis credentials, DNS, NetworkPolicy egress, and plugin activation have to be treated as one path, not separate toggles.

Plugin installation belongs in the chart when the volume is persistent

Manual plugin installation through wp-admin is easy, but it creates invisible drift. A second environment, a recreated PVC, or a disaster recovery run will not necessarily have the same plugin state.

The chart can install official WordPress.org plugin slugs through an idempotent Job:

persistence:
  enabled: true

plugins:
  enabled: true
  installer:
    enabled: true
    activeDeadlineSeconds: 60
    backoffLimit: 1
    preferWordPressPodNode: true
  items:
    - slug: classic-editor
      activate: true
      skipIfInstalled: true
    - slug: contact-form-7
      activate: true
      skipIfInstalled: true

The storage requirement is intentional. The installer writes into the same WordPress files that the web pod serves. With a ReadWriteOnce volume, the Job also has to run in a way that respects where the PVC can attach. That is why the chart supports a node preference for the existing WordPress pod and keeps the installer timeout short by default.

For production, treat plugin lists as part of your release process. The chart can install plugins, but it cannot decide whether a plugin is safe, maintained, compatible with your WordPress/PHP version, or acceptable for your security policy.

Backup must include database and content

WordPress state is split. Posts, options, users, and plugin settings live in MySQL/MariaDB. Uploads, themes, plugin files, and object-cache drop-ins live under /var/www/html, especially wp-content.

A database-only backup is not a WordPress restore plan. A filesystem-only backup is not a WordPress restore plan either.

The chart’s backup CronJob exports both:

backup:
  enabled: true
  schedule: '0 3 * * *'
  archivePrefix: wordpress
  s3:
    endpoint: https://s3.amazonaws.com
    bucket: wordpress-backups
    existingSecret: wordpress-s3
    existingSecretAccessKeyKey: access-key
    existingSecretSecretKeyKey: secret-key
  database:
    mysqldumpArgs: '--single-transaction --quick --skip-lock-tables --no-tablespaces'

The output is two artifacts: a compressed database dump and a compressed wp-content archive.

Run an on-demand backup before you trust the schedule:

kubectl create job -n wordpress \
  --from=cronjob/wordpress-backup \
  wordpress-backup-manual

kubectl logs -n wordpress job/wordpress-backup-manual -f

Then test restore. The backup job can prove it uploaded files. Only restore proves those files are sufficient.

External Secrets keeps values files clean

Many charts support existingSecret, and that is still the runtime contract. External Secrets Operator adds the missing platform workflow: credentials can live in AWS Secrets Manager, Vault, Azure Key Vault, GCP Secret Manager, or another backend, while the chart consumes ordinary Kubernetes Secrets.

externalSecrets:
  enabled: true
  apiVersion: external-secrets.io/v1
  secretStoreRef:
    name: vault
    kind: ClusterSecretStore
  admin:
    enabled: true
    passwordRemoteRef:
      key: prod/wordpress
      property: admin-password
  database:
    enabled: true
    passwordRemoteRef:
      key: prod/wordpress
      property: database-password
  backup:
    enabled: true
    accessKeyRemoteRef:
      key: prod/wordpress-backup
      property: access-key
    secretKeyRemoteRef:
      key: prod/wordpress-backup
      property: secret-key

That separation is useful in GitOps. The values file can describe which secret is needed without carrying the secret value.

Scaling WordPress is mostly a storage question

It is tempting to set replicaCount: 3 or enable HPA and call the setup highly available. For WordPress, that is only correct when the content layer supports it.

The default ReadWriteOnce PVC is right for a single pod. Multiple WordPress pods need one of these strategies:

• ReadWriteMany storage for /var/www/html.
• a custom immutable image with plugins/themes baked in and uploads handled elsewhere.
• object-storage media integration outside the chart.
• a careful split where only safe paths are shared and writable paths are externalized.

Without that decision, multiple pods can disagree about plugins, themes, uploads, and drop-ins. The chart exposes HPA and PDB, but production operators should enable them only after the storage architecture is ready.

The production validation checklist

Before calling the install production-ready, validate the behavior from Kubernetes and WordPress:

kubectl get pods,pvc,svc,httproute,networkpolicy -n wordpress
kubectl get externalsecret,secret -n wordpress
kubectl describe pod -n wordpress -l app.kubernetes.io/name=wordpress
kubectl logs -n wordpress deploy/wordpress

Check the application path:

kubectl exec -n wordpress deploy/wordpress -- \
  wp core version --path=/var/www/html --allow-root

kubectl exec -n wordpress deploy/wordpress -- \
  wp plugin list --path=/var/www/html --allow-root

kubectl exec -n wordpress deploy/wordpress -- \
  wp redis status --path=/var/www/html --allow-root

Check backup:

kubectl get cronjob,job -n wordpress
kubectl logs -n wordpress job/wordpress-backup-manual -f

Check routing:

kubectl get httproute -n wordpress
kubectl get gateway -A
curl -I https://blog.example.com

Those checks catch the failures that a simple Helm render cannot: PVC attachment, plugin writes, Redis connectivity, route attachment, ExternalSecret reconciliation, and backup upload permissions.

A good chart should make the tradeoffs visible

The goal is not to pretend WordPress becomes stateless because it runs in Kubernetes. It does not.

The goal is to make the state boundaries visible: database, content volume, object cache, plugins, secrets, routing, backup, and scheduled jobs. Once those are visible in values, production review becomes practical. You can ask whether Redis is local or external, whether the backup includes both domains, whether plugins are part of release management, whether NetworkPolicy still allows Redis and MySQL, and whether the storage class can support the number of replicas requested.

That is where Helm adds value. Not by hiding WordPress behind a single command, but by turning the production shape into something the platform can review, test, repeat, and restore.
